6 Head Computer Embroidery Machine
commercial computerized embroidery machine, 6 heads × 9/12/15 needles, 400 × 450 mm area, 1000 SPM, up to 850 pieces per 8-hour shift. AC servo motor, Topwisdom touch panel, auto trim and color change, 270° cap frame. CE/SGS/ISO9001....
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
WONYO 6 Head Computerized Embroidery Machine - 9/12/15 Needles
Six heads stitch six identical pieces at once. 400 × 450 mm field per head, up to 1000 SPM, AC servo main motor and 270° wide cap frame. Flat, cap, finished-garment, leather and bag embroidery on one frame set. Built for shops moving from daily small batches to scheduled bulk orders.
一：Product Specifications
| Item | Spec |
|---|---|
| Model | WY906C / WY1206C / WY1506C |
| Heads × Needles | 6 heads × 9 / 12 / 15 needles |
| Embroidery area | 400 × 450 mm per head |
| Max speed | 1000 SPM |
| Main motor | AC servo |
| XY drive | Stepper motor |
| Control | Topwisdom touch screen, multi-language, DST/DSB via USB |
| Memory | 20,000,000 stitches / 200 designs |
| Auto functions | Trim, color change, thread-break detection, pre-sew trace, power-off resume |
| Voltage / Power | AC100–250V self-adapting, 1000W, 50/60Hz |
| Gross weight | 1100 kg |
| Certification | CE, SGS, ISO9001 |
二：Product Features
1.6 heads, one cycle = 6 pieces - For the same badge/logo, 10,000 stitches produce 6 pieces in about 15 minutes, cutting group-order lead times from weeks to days.
2.AC servo main shaft motor - Stable needle positioning at high speed; consistent stitching across all 6 heads, with no color or stitch variation from head to head.
3.9/12/15 needles selectable - 9 needles cover standard logos, while 15 needles run multi-color designs in one pass without re-threading.
4.270° wide-angle cap frame - Enables batch embroidery on both front and back cap positions; switching to flat embroidery requires no re-punching (no new digitizing needed).
5.Thread break detection + power-off resume + preview tracing frame - Minimizes losses from scrapping all 6 heads at once; even beginners can check the design pattern easily.
6.Optional devices - 3D puff, sequin, cord/tape, chenille (towel), and boring attachments can be added later to take on higher-value orders.
三：Application Areas (Mass-Production Capacity)
1.Uniform & group-wear factories - Batch embroidery of the same logo for school uniforms, workwear, and team apparel.
2.Promotional cap / sports cap production lines - High-volume embroidery on the cap front, with a daily capacity of 600+ caps.
3.Garment factory support process - Chest and back embroidery for T-shirts, polos, jackets, and leather garments.
4.Bag & footwear OEM subcontracting - Batch embroidery of logos on bag surfaces and shoe uppers as a supplementary process.
II. Computer system
1. New 10" touch screen display control panel
2. Showing real time stitching
3. Function keys including selection key, manual trimmer, arrow keys.
4. Selection can be used to speed up and slow down
5. Memory size: 2,000,000 stitches
6.The processor is 150MHZ with fast system speed
7. USB port ready
8. control system can be updated easily
9. Interface is user friendly and easy to handle
10.Multi Languages available (English, Spanish, Portuguese, French, Russian, German. Dutch etc.)
Cap Attachment Included
Packing and Delivery
Delivery term: Production takes around 13 days ship within 7-10days after receiving 100% payment
Payment term: 30% TT advance payment before production, 70% TT remaining balance before shipping.
FAQ
Q&A:Hot Questions from Customers
1: 6-head or 4-head - which should I buy?
A: 6 heads add 50% output over 4 heads for roughly 25–30% more cost. Choose 6 heads if you already have repeat bulk orders; stay with 4 heads if orders are mixed and small.
Q 2 :How many pieces per day?
A:600–900 pieces per 8-hour shift on standard 8,000–10,000 stitch logos; caps around 600/day.
Q 3 :Why is your price $9,500 when Tajima is $40,000+?
A:Same core function, different control system and service network. Ours uses Topwisdom panels with local remote support; Japanese brands charge for global service infrastructure.
Q 4 :What floor space and power do I need?
A: About 3.5 × 1.2 m plus 1 m clearance on each side; AC100–250V, 1000W single-phase, level floor rated for 1.2 t.
Q 5 : Are 15 needles worth the extra cost?
A:Yes if designs use 8+ colors regularly; 9 needles cover most logo work at a lower price.
Q 6 :Lead time and payment?
A: 13–25 days production; 30% T/T deposit, 70% before shipment.
Q 7 : How could you make sure my order and payment safe?
A: We are a certified supplier by China government and Alibaba , and you can apply a trade assurance through Alibaba to place order
Q 8 :What kind of warranty will you provide ?
A: We provide one year warranty of the overall machine and two years of electronic parts and free upgrade for control system. We also provide normal mechanical parts as spares in tool boxes.
Always find agent all over the world!
Please whatsapp Nicki with #+8618696118389
Other Models:
| Model | Needle | Head | N.weight | Embroidery area |
| WY1202C/902C | 12/9 | 2 | 450kg |
400*450mm |
| WY1204C/904C | 12/9 | 4 | 700kg | 400*450mm |
| WY1206C/906C | 12/9 | 6 | 1100kg | 400*450mm |
| WY1208C/908C | 12/9 | 8 | 1200kg | 400*450mm |
| WY1212C/912C | 12/9 | 12 | 1800kg | 400*450mm |
